Heavy-Duty Pin-On Buckets
LIGHTWEIGHT, LONG LIFE, HEAVY-DUTY CAPABILITIES
Innovative design and advanced materials mean these heavy-duty buckets embody the ultimate combination for job site productivity. Paladin’s Heavy Duty Pin-On Buckets offer a lighter-weight bucket with significant wear resistance using AR400 material (highlighted in red in renders).
- FEATURES
- SPECIFICATIONS
- INDUSTRIES
- LITERATURE
Prime Mover: Mini-Excavator and Backhoe Loader
- AR400 Wear-Resistant Plate: Used to reduce the weight of the bucket and improve the wear life (areas in red in the images above show where the AR400 plate is used)
- Dual Taper Design: provides enhanced heel clearance for less resistance and wear while digging
- Long Floor Design: provides for easier trenching and better filling of the bucket
| Prime Mover Size | Width (in) | Capacity (ft3) | # of Teeth | Weight (lb) |
|---|---|---|---|---|
| 2T | 12 | 1.04 | 3 | 102 |
| 2T | 18 | 1.65 | 4 | 131 |
| 2T | 24 | 2.35 | 5 | 163 |
| 3T | 12 | 1.5 | 3 | 139 |
| 3T | 18 | 2.38 | 4 | 171 |
| 3T | 24 | 3.45 | 5 | 207 |
| 5T | 12 | 2.17 | 3 | 158 |
| 5T | 18 | 3.44 | 4 | 192 |
| 5T | 24 | 5 | 5 | 231 |
| 5T | 30 | 6.56 | 5 | 265 |
| 8T & LBH | 12 | 3.05 | 3 | 278 |
| 8T & LBH | 18 | 5.58 | 4 | 311 |
| 8T & LBH | 24 | 8.28 | 5 | 370 |
| 8T & LBH | 30 | 11.09 | 5 | 422 |
| 8T & LBH | 36 | 13.93 | 6 | 481 |
Agriculture
Construction
Demolition and Recycling
Forestry
Land Management
Material Handling
JRB Heavy-Duty Pin-On Buckets
