High-Capacity Buckets
The JRB High Capacity series of excavator buckets has been designed to maximize capacity in high production, low material density applications. These buckets are ideal for bulk excavation of lower density materials such as mulch, peat, topsoil, and similar materials with densities of 1600 lbs/yd³.
- FEATURES
- SPECIFICATIONS
- INDUSTRIES
- LITERATURE
Prime Mover: Excavator
Maximum Capacity
- Over 18% increase in capacity vs. a typical heavy-duty bucket for larger payloads
- Capacity and bucket weight have been optimized to work with OEM standard and mass excavation arms configurations
Enhanced Performance
- Optimized profile for better filling and dumping
- Dual taper design provides enhanced heel clearance for less resistance and wear during digging
Enhanced Durability
- Reinforced header construction for superior durability in high cycle applications
- Strategic placement of AR400 wear material in the cutting edge, side cutter, and bottom corner to reduce wear
| Excavator | Width (in) | Rated Capacity (yd3) | # of Teeth | Weight (lb) |
|---|---|---|---|---|
| 35T | 66 | 3.53 | 6 | 4,074 |
| 35T | 72 | 3.92 | 7 | 4,358 |
| 45T | 72 | 4.82 | 7 | 5,080 |
| 45T | 84 | 5.76 | 8 | 5,635 |
Agriculture
Construction
Land Management
Material Handling
JRB High Capacity Excavator Buckets
